+66 88 984 8897Drawbar and wheels for HM1100-01 lift
Article: 300-170HM
HERKULES / HEDSON
Herkules HM 1100 onground
Wheel-free access for workshop tasks.
A pneumatic chassis-support lift for wheel-free access. Review vehicle lifting points, mass and available working clearance with M&H.
- Air supply
- 6-8 bar
- Lifting capacity (kg)
- 2800 kg
- Lifting height (mm)
- 930 mm
YOUR WORKSHOP
Specify the equipment with M&H.
Share vehicle types and maximum mass, wheelbase, bay dimensions and available compressed air. Add a floor, pit or rail drawing where relevant.
Vehicle suitability depends on the support points, dimensions and load distribution, not capacity alone.
Herkules HM 1100 onground
Wheel-free lifting under the chassis, with an onground installation. Select the lifting points, vehicle dimensions and installation space for the intended work.
PRODUCT DETAILS
The essential details.
| Weight (kg) | 510 kg |
|---|---|
| Length (mm) | 1704 mm |
| Height (mm) | 115 mm |
| Width / depth (mm) | 1100 mm |
| Air supply | 6-8 bar |
| Onground or inground | onground |
| Lifting capacity (kg) | 2800 kg |
All technical specifications
| Weight (kg) | 510 kg |
|---|---|
| Length (mm) | 1704 mm |
| Height (mm) | 115 mm |
| Width / depth (mm) | 1100 mm |
| Air supply | 6-8 bar |
| Onground or inground | onground |
| Lifting capacity (kg) | 2800 kg |
| Lifting height (mm) | 930 mm |
| Overdrive height (mm) | 115 mm |
Lifting and safety configuration
| Lifting on wheels | NO |
|---|---|
| Lifting on chassis | YES |
| With CE stop | NO |
Vehicle suitability depends on the support points, dimensions and load distribution, not capacity alone.
Installation and operation
Follow the operating manual for the exact equipment. M&H can help identify the correct configuration, installation documents and service requirements.
