IRT iCure 2 Robotic IR/UV LED Dryer

IRT product overview

What this product does and where it fits in the workshop.

Compare the product role, workshop use case, technical snapshot, and next-step guidance before requesting a quote.

What it does

Compare IRT iCure 2 as a compact robotic rail dryer combining infrared and UV LED curing, dynamic or static operation, preprogrammed and custom recipes, and manual cassette positioning for planned spray-booth or prep-zone installation.

  • Combines IRT shortwave infrared and UV LED curing in one compact robotic rail platform.
  • Supports dynamic and static curing with preprogrammed and user-defined recipes.
  • Robotic travel can operate along the long or short side of the vehicle while the cassette remains manually adjustable.
  • The cassette rotates from 0 to 90 degrees and adjusts vertically through 0-480 mm for flexible positioning.
  • Hedson states IR lamp life up to 20,000 hours and identifies the platform for spray-booth or prep-zone retrofit.
Best for

Common workshop applications and customer outcomes.

  • Robotic spray-booth curing
  • Prep-zone IR and UV LED curing
  • Dynamic vehicle-side drying
  • Static panel curing
  • Recipe-controlled bodyshop production
Technical snapshot

Key specification points that make the product easier to compare.

Article no.737413
Curing technologiesIRT shortwave infrared and UV LED
InstallationRobotic rail dryer for retrofit in spray booths and prep zones
Operating modesDynamic and static curing
RecipesPreprogrammed and user-defined curing recipes
supplier page

Open the supplier product page when you need the manufacturer reference behind this recommendation.

Open official page

IRT robotic IR and UV LED curing

Plan the rail, recipes, and material process before selecting iCure 2.

IRT iCure 2 is a compact robotic rail dryer for spray booths and prep zones. It combines IR and UV LED curing with automated long- or short-side travel, dynamic and static modes, and flexible manual cassette positioning.

IR + UV LEDtwo curing technologies
0-90 degreescassette rotation
0-480 mmvertical cassette adjustment

What to confirm before selecting IRT iCure 2

  • Spray-booth or prep-zone dimensions, rail path, vehicle clearances, parking position, and service access
  • IR and UV-activated material systems, dynamic or static recipes, repair sizes, and production targets
  • 400-480 V three-phase power, 26 A full-load current, 32 A disconnect fuse, and local electrical work
  • Installation engineering, operator recipe training, UV safety, lamp and LED service, and production governance

IRT iCure 2 Robotic IR/UV LED Dryer

How iCure 2 supports a controlled curing process

The project should be designed around the booth, material system, and production option rather than treated as a standalone dryer purchase.

01

Survey the zone

Measure the booth or prep area, vehicle envelope, rail travel, parking position, utilities, and service clearance.

02

Define the recipes

Map IR and UV LED materials, repair sizes, dynamic or static cycles, and production targets.

03

Automate the movement

Use programmed long- or short-side travel and adjust the cassette angle and height for the repair.

04

Control the process

Train operators, validate recipes, record maintenance, and plan IR lamp, UV LED, and rail-system service.

IRT iCure 2 Robotic IR/UV LED Dryer

Who should review iCure 2 first

iCure 2 is strongest where a professional bodyshop is ready to engineer curing into the booth or preparation workflow.

OEM and dealer bodyshops

Standardize IR and UV LED recipes in planned spray-booth or prep-zone production.

High-output collision centers

Automate vehicle-side curing movement and reduce manual dryer repositioning.

MSO technical teams

Review repeatable installation, recipes, safety, training, and service across sites.

APAC distributors

Coordinate layout, power, installation, commissioning, operator training, and aftersales support.

IRT iCure 2 Robotic IR/UV LED Dryer

Choose iCure 2 when robotic rail curing matches the production plan.

Choose when
A spray booth or prep zone needs automated IR and UV LED curing with dynamic and static recipes.
Compare with
Mobile IRT dryers for flexible local work, or larger fixed rail systems for different bay coverage.
Check first
Layout, rail path, material compatibility, recipes, electrical supply, safety, installation, service, and training.

IRT

Continue the IRT curing option

IRT UV SmartCureA compact UV curing system built for minor to moderate repairs where the workshop needs fast, controlled curing in seconds rather than minutes.IRT UV SpotCure2An evolved UV LED curing tool that combines higher power and a larger curing area for efficient spot repair work.IRT Prep X LDPAn infrared dryer for prep-stage work with temperature control and laser distance guidance to help technicians stay consistent.IRT Prep 4 Infrared Prep DryerA controlled infrared prep dryer for flash-off and full bake work with time control and visible energy use feedback.

IRT iCure 2 buyer questions

Confirm the robotic option, curing technologies, and installation data.

iCure 2 is an installed rail platform, so product selection and site engineering belong in the same review.

Question 1

What is IRT iCure 2?

Hedson describes iCure 2 as a compact robotic IR and UV LED rail dryer for retrofit in spray booths and prep zones.

Question 2

Can iCure 2 cure dynamically and statically?

Yes. The official page lists dynamic and static drying, preprogrammed recipes, user-defined recipes, and robotic movement along the long or short side of a vehicle.

Question 3

What electrical supply does iCure 2 require?

Hedson lists 400-480 V three phase/PE at 50-60 Hz, 26 A full-load current, and a 32 A main disconnect fuse.

Question 4

What should be supplied for an iCure 2 quote?

Provide booth or prep-zone drawings, vehicle sizes, material systems, repair areas, curing targets, rail direction, power, safety requirements, installation scope, training, and service access.

Technical data

Key points for comparing this product.

Use these rows as a technical comparison starting point. Final model, options, utilities, consumables, training, and installation details should be confirmed before preparing a quote.

Available technical rows
Article no.
737413
Curing technologies
IRT shortwave infrared and UV LED
Installation
Robotic rail dryer for retrofit in spray booths and prep zones
Operating modes
Dynamic and static curing
Recipes
Preprogrammed and user-defined curing recipes
Robotic travel
Automated movement along the long or short side of the vehicle
Cassette rotation
Manual 0-90 degrees
Cassette vertical adjustment
0-480 mm
IR lamp life
Up to 20,000 hours stated by Hedson
Nominal frequency
50-60 Hz
Rated voltage
400-480 V, three phase/PE, +/- 5%
Full load current
26 A
Main disconnect fuse
32 A
Sound pressure / power level
Up to 70 dB(A) at 1 m
Maximum operating ambient temperature
40 C
Confirm before quote
Confirm booth or prep-zone layout, rail option, IR and UV materials, recipes, power, safety, installation, training, and service access
Curing technology
Shortwave infrared and UV LED
Unit format
Compact robotic rail dryer for spray booths and prep zones
Repair scope
IR and UV LED curing in planned spray-booth and prep-zone production
Control method
Robotic long- or short-side travel with dynamic/static recipes and manual cassette positioning
Curing modes
Dynamic and static curing with preprogrammed and user-defined recipes
Robotic movement
Automated travel along the long or short side of the vehicle
Manual positioning
Cassette rotation 0-90 degrees and vertical adjustment 0-480 mm
Electrical supply
400-480 V three phase/PE, 50-60 Hz, 26 A full load, 32 A disconnect fuse
Operating environment
Maximum 40 C ambient and up to 70 dB(A) at 1 m
Workspace fit
Installed production option requiring layout, rail, material, safety, commissioning, and service planning
Product role
Robotic rail dryer for spray booths and prep zones
Common applications
Robotic spray-booth curing, Prep-zone IR and UV LED curing, Dynamic vehicle-side drying
